SW22

SW22

Water Baths

Part Number: 9550322

JULABO SW shaking water baths for unsupervised sample incubation. Stainless steel construction with an operating range from +20…+99.9 °C. User-friendly operation via keypad with bright LED display. Electronic timer from 1 min to 9h 59min. Integrated RS232 interface for integration to PC software for control and data logging. Early low water level warning system. Early warning system with high and low temperature limits ensures that samples maintain the proper temperature. A removable shaking carriage for easy sample removal. A wide range of accessories, including bath covers, are available. Shaking frequency adjustable from 20 to 200 rpm. Shaking stroke = 15 mm.
SW22 unit with ±0.2 °C stability. SW23 incorporates a water circulation pump for a stability of ±0.02 °C.

Protects samples from contamination to +80°C.

$4,631.00 +

Quantity:
Part Number
9550322.2
9550322.3
9550322.2.CSA/UL
9550322.3.LID
9550322.2.LID
9550322.2.CSA/UL.LID
Voltage Version
115V/60Hz
230V/50-60Hz
115V/60Hz
230V/50-60Hz
115V/60Hz
115V/60Hz
NRTL
No
No
Yes
No
No
Yes
Heating & Cooling
Heating
Heating
Heating
Heating
Heating
Heating
Working Temp Range (°C)
20...99
20...99
20...99
20...99
20...99
20...99
PCF Pressure (psi)
PCF Rate (l/min)
$4,631.00
$4,631.00
$5,431.00
$4,631.00
$4,631.00
$5,431.00
Part Number
9550322.2
9550322.3
9550322.2.CSA/UL
9550322.3.LID
9550322.2.LID
9550322.2.CSA/UL.LID
Working Temp Range (°C)
20...99
20...99
20...99
20...99
20...99
20...99
Heating Capacity (kW)
1
2
1
2
1
1
Cooling Capacity
Voltage Version
115V/60Hz
230V/50-60Hz
115V/60Hz
230V/50-60Hz
115V/60Hz
115V/60Hz
Power A
9A
9A
9A
9A
9A
9A
Plug Type
NEMA 6-20P
NEMA 5-15P
NEMA 5-15P
NRTL
No
No
Yes
No
No
Yes
PCF Pressure (psi)
PCF Rate (l/min)
Bath Fill Volume (L)
8…20
8…20
8…20
8…20
8…20
8…20
External Devices
Remote Control
Remote Control
Remote Control
Remote Control
Remote Control
Remote Control
Fluid Type
Water
Water
Water
Water
Water
Water
Heating & Cooling
Heating
Heating
Heating
Heating
Heating
Heating
Dimensions W x L x H (in)
27.6 x 13.8 x 10.2
27.6 x 13.8 x 10.2
27.6 x 13.8 x 10.2
27.6 x 13.8 x 10.2
27.6 x 13.8 x 10.2
27.6 x 13.8 x 10.2
Weight (lbs)
49
49
49
49
49
49
$4,631.00
$4,631.00
$5,431.00
$4,631.00
$4,631.00
$5,431.00
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
  • MICROPROCESSOR technology with PID temperature control
  • Bright MULTI-DISPLAY (LED)
  • Seamless, splash-proof keypad
  • Splash-proof mains switch
  • Electronic timer for setting the running time (0:01 to 9:59 h:min)
  • On-line communication via built-in RS232 interface
  • Early warning system with high and low temperature limits
  • Drain screw for conveniently emptying the bath
  • Dry-running protection / safety temperature fixed at 105 °C
  • Wide range of accessories including lift-up Makrolon bath cover available
  • EasyTemp control software is available free of charge
  • Removable shaking carriage
  • Shaking frequency adjustable from 20 to 200 rpm
  • Shaking frequency indicated on MULTI-DISPLAY (LED)
  • Shaking stroke 15 mm
  • Adapters
    Elbows M16x1 8891242 $323.00 View
  • Bath Covers
    Lift-up plastic cover 8970288 SW22/SW23 $456.00 View
  • Certificates
    Manufacturer’s Certificate Category 1 $173.00 View
  • Clamps
    Spring clamp basic tray 8970620 $363.00 View
    Universal tray for spring clamps 8970630 $588.00 View
    Spring clamps set 8970631 $132.00 View
    10mL Spring clamps 8970601 $48.00 View
    25mL Spring clamps 8970602 $51.00 View
    50mL Spring clamps 8970603 $57.00 View
    100mL Spring clamps 8970604 $67.00 View
    250mL Spring clamps 8970606 $81.00 View
    300mL Spring clamps 8970607 $81.00 View
    500mL Spring clamps 8970608 $91.00 View
    1L Spring clamps 8970609 $107.00 View
  • Cooling Coils
    Liquid level/cooling set 8970415 $446.00 View
  • Networking & Software
    SW baths RS232 cable 8980075 $158.00 View
  • Test tube racks
    TT rack 31mm SW baths 8970347 $244.00 View
    Carrier trays 8970360 25mL $563.00 View
    Carrier trays 8970361 50mL $463.00 View
    Carrier trays 8970362 100mL $426.00 View
    Carrier trays 8970363 200mL $479.00 View
    Carrier trays 8970364 300mL $533.00 View
    Carrier trays 8970365 500mL $350.00 View
    Carrier trays 8970366 1L $564.00 View
    TT rack Basic tray 8970369 $344.00 View
    TT rack, 17mm OD 8970380 $134.00 View
    TT rack, 12mm OD 8970382 $180.00 View
    TT rack, 31mm OD 8970383 $127.00 View
    Carrier tray 4x TT racks 16/17mm 8960440 $757.00 View
    Carrier tray 4xTT racks 12/13mm 8960441 $757.00 View
    Carrier tray 4x TT racks 11/12mm 8960442 $874.00 View
    TT rack 15/17mm SW baths 8970344 $252.00 View
    TT rack 13mm SW baths 8970345 $252.00 View
    TT rack 12mm SW baths 8970346 $258.00 View
  • Valves
    Bath Drain tap 8970453 $188.00 View
